SPS50000C

The Sany Palfinger SPS50000C series of rigid boom cranes are particularly suitable for heavy lifting tasks that require high loads and complex operating environments. The SPS50000C model has a rated lifting capacity of 20000kg, a four-section boom design, a maximum boom length of 21.6m, and a lifting height of up to 23.1m.
The crane is equipped with a hydraulic system that runs at a recommended flow rate of 80L/min-110L/min and is equipped with a 300L fuel tank. It achieves optimal performance while maintaining a lightweight design, with a deadweight of only 6800kg.
The system pressure is 32MPa, which provides excellent lifting capacity and can handle a variety of demanding tasks. Whether it is a construction project or a logistics operation, it can provide reliable and efficient solutions for various lifting applications.

Stiff Boom Crane Series SPS50000C Application Areas

Construction Site: Used for lifting heavy building materials such as steel beams, concrete slabs, etc. on construction sites.
Ports and logistics: used for lifting, loading and unloading of containers.
Transportation and installation: Widely used in the transportation and installation of large mechanical equipment.
Power and Energy: Used for lifting heavy equipment in power construction projects.

Technical Specifications

Stiff Boom Crane Series	SPS50000C
Rated lifting weight	20000kg
Numbers of the boom	5
Length of fully extended boom	21.6m
Max lifting height	23.1m
Outrigger span (fully extended)	7250mm
Recommend flow of the system	80L/min-110/min
Recommend volume of the oil tank	300L
Deadweight of the crane	6800kg
Rated pressure of the system	32Mpa
Lead Time	15-30 Working Days
Payment Terms	T/T ,L/C

coming soon

Truck Model	Rated lifting weight	Max lifting height	Outrigger span (fully extended)	Rated pressure of the system
SPS50000C	20000kg	23.1m	6800mm	32Mpa
—–END—–

Main parameters
Stiff Boom Crane Series	SPS50000C	Rated pressure of the system	32Mpa
Rated lifting weight	20000kg	Numbers of the boom	5
Length of fully extended boom	21.6m	Max lifting height	23.1m
Outrigger span (fully extended)	7250mm	Recommend flow of the system	80L/min-110L/min
Recommend volume of the oil tank	300L	Deadweight of the crane	6800kg
—–END—–

What is the price?

Our prices are determined by many factors, including model, power, product configuration, quantity, price terms (FOB, CIF, CPT, FCA, etc.), etc.

Is there a warranty and how long is it?

We can provide warranty service. The warranty period for different models is different. It depends on the specific situation and can be negotiated.

Is the Price Reasonable?

We are the original manufacturer and can give you the most suitable price. The key to dealing with Chinese suppliers is to find and choose reliable business partners who will not deceive you for short-term business, but aim to establish a long-term career and lifelong partnership. EMAC is one of the reliable partners. We will not pursue short-term high profits, but we care about our decades of good reputation. Our cooperation with all business partners is not only as suppliers and customers, but also as close friends and brothers.

How about after-sales service and maintenance?

We provide repair and maintenance services abroad. In addition, we can provide end customers with electronic versions of “Engine Operation and Maintenance Manual”, “Parts Atlas”, “Repair Manual” and other materials, covering the full range of export products, and provide reliable technical guidance for market service training.
