SPS20000C-HPro
The SANY Palfinger stiff boom arm crane SPS20000C-HPro delivers exceptional lifting performance and versatility, boasting a maximum lifting moment of 20 mt and a capacity of 8000 kg at a 2.5 m radius. With a hydraulic outreach of 18.3 m across its 5 boom sections and a lifting height of up to 20.4 m (stabilizers fully extended), it is designed for demanding operations. The boom offers a length range from 5.5 m to 18.7 m and operates at angles from 0° to 75°, ensuring flexibility for various applications. Stability is guaranteed with a stabilizer spread of 7250 mm, while the high-seat control system enhances precision and user comfort. Weighing 4100 kg, this crane combines robust performance with compact design, making it an ideal choice for efficient and reliable lifting solutions.
Stiff Boom Crane Series SPS20000C-Hpro Application Areas
Construction Site: Used for lifting heavy building materials such as steel beams, concrete slabs, etc. on construction sites.
Ports and logistics: used for lifting, loading and unloading of containers.
Transportation and installation: Widely used in the transportation and installation of large mechanical equipment.
Power and Energy: Used for lifting heavy equipment in power construction projects.
Technical Specifications
| Stiff Boom Crane Series | SPS20000C-Hpro |
| Lifting moment | 20mt |
| Max. lifting capacity | 8000kg/2.5m |
| Hydraulic outreach | 18.3m(5 booms) |
| Max. lifting height | 20.4m |
| Boom length(Fully retract – Fully Extend) | 5.5m-18.7m |
| Main boom angle | 0°to 75° |
| Stabilizer spread | 7250mm |
| Control system | High seat |
| Crane weight of standard model | 4100kg |
| Lead Time | 15-30 Working Days |
| Payment Terms | T/T ,L/C |
Truck Model | Lifting moment | Max. lifting capacity | Max. lifting height | Control system |
| SPS20000C-Hpro | 20mt | 8000kg/2.5m | 20.4m | High seat |
| —–END—– | ||||
| Main parameters | ||||
| Stiff Boom Crane Series | SPS20000C-Hpro | Lifting moment | 20mt | |
| Max. lifting capacity | 8000kg/2.5m | Hydraulic outreach | 18.3m | |
| Max. lifting height | 20.4m | Boom length(Fully retract – Fully Extend) | 5.5m-18.7m | |
| Main boom angle | 0°to 75° | Stabilizer spread | 7250mm | |
| Control system | High seat | Crane weight of standard model | 4100kg | |
| —–END—– | ||||
What is the price?
Our prices are determined by many factors, including model, power, product configuration, quantity, price terms (FOB, CIF, CPT, FCA, etc.), etc.
Is there a warranty and how long is it?
We can provide warranty service. The warranty period for different models is different. It depends on the specific situation and can be negotiated.
Is the Price Reasonable?
We are the original manufacturer and can give you the most suitable price. The key to dealing with Chinese suppliers is to find and choose reliable business partners who will not deceive you for short-term business, but aim to establish a long-term career and lifelong partnership. EMAC is one of the reliable partners. We will not pursue short-term high profits, but we care about our decades of good reputation. Our cooperation with all business partners is not only as suppliers and customers, but also as close friends and brothers.
How about after-sales service and maintenance?
We provide repair and maintenance services abroad. In addition, we can provide end customers with electronic versions of “Engine Operation and Maintenance Manual”, “Parts Atlas”, “Repair Manual” and other materials, covering the full range of export products, and provide reliable technical guidance for market service training.
Note: All Above Data are Just for Reference, All Data Might Change Without Notices or Updates, Please Contact Our Sales Team to Confirm All Details Via WhatsApp or Email.
