SPS 10.000B SLD1
The Sany Palfinger SPS 10.000B SLD1 series of rigid boom cranes are particularly suitable for heavy lifting tasks that require high loads and complex operating environments. The SPS 10.000B SLD1 model has a rated lifting capacity of 3870kg, a four-section boom design, a maximum boom length of 10.4m, and a lifting height of up to 12.5m.
The crane is equipped with a hydraulic system that runs at a recommended flow rate of 35L/min and is equipped with a 30L fuel tank. It achieves optimal performance while maintaining a lightweight design, with a deadweight of only 1309kg.
The system pressure is 25MPa, which provides excellent lifting capacity and can handle a variety of demanding tasks. Whether it is a construction project or a logistics operation, it can provide reliable and efficient solutions for various lifting applications.
Stiff Boom Crane Series SPS 10.000B SLD1 Application Areas
Construction Site: Used for lifting heavy building materials such as steel beams, concrete slabs, etc. on construction sites.
Ports and logistics: used for lifting, loading and unloading of containers.
Transportation and installation: Widely used in the transportation and installation of large mechanical equipment.
Power and Energy: Used for lifting heavy equipment in power construction projects.
Technical Specifications
| Stiff Boom Crane Series | SPS 10.000B SLD1 |
| Rated lifting weight | 3870kg |
| Numbers of the boom | 4 |
| Length of fully extended boom | 10.4m |
| Max lifting height | 12.5m |
| Outrigger span (fully extended) | 4400mm |
| Recommend flow of the system | 35L/min |
| Recommend volume of the oil tank | 30L |
| Deadweight of the crane | 1309kg |
| Rated pressure of the system | 25Mpa |
| Lead Time | 15-30 Working Days |
| Payment Terms | T/T ,L/C |
Truck Model | Rated lifting weight | Max lifting height | Outrigger span (fully extended) | Rated pressure of the system |
| SPS 10.000B SLD1 | 3870kg | 10.4m | 4400mm | 25Mpa |
| —–END—– | ||||
| Main parameters | ||||
| Stiff Boom Crane Series | SPS 10.000B SLD1 | Rated pressure of the system | 25Mpa | |
| Rated lifting weight | 3870kg | Numbers of the boom | 4 | |
| Length of fully extended boom | 10.4m | Max lifting height | 12.5m | |
| Outrigger span (fully extended) | 4400mm | Recommend flow of the system | 35L/min | |
| Recommend volume of the oil tank | 30L | Deadweight of the crane | 1309kg | |
| —–END—– | ||||
What is the price?
Our prices are determined by many factors, including model, power, product configuration, quantity, price terms (FOB, CIF, CPT, FCA, etc.), etc.
Is there a warranty and how long is it?
We can provide warranty service. The warranty period for different models is different. It depends on the specific situation and can be negotiated.
Is the Price Reasonable?
We are the original manufacturer and can give you the most suitable price. The key to dealing with Chinese suppliers is to find and choose reliable business partners who will not deceive you for short-term business, but aim to establish a long-term career and lifelong partnership. EMAC is one of the reliable partners. We will not pursue short-term high profits, but we care about our decades of good reputation. Our cooperation with all business partners is not only as suppliers and customers, but also as close friends and brothers.
How about after-sales service and maintenance?
We provide repair and maintenance services abroad. In addition, we can provide end customers with electronic versions of “Engine Operation and Maintenance Manual”, “Parts Atlas”, “Repair Manual” and other materials, covering the full range of export products, and provide reliable technical guidance for market service training.
Note: All Above Data are Just for Reference, All Data Might Change Without Notices or Updates, Please Contact Our Sales Team to Confirm All Details Via WhatsApp or Email.
