SPK74002F
The Sany Palfinger articulated boom crane SPK74002F series has a powerful lifting moment of 70.1 metric tons and a maximum lifting capacity of 21000 kg, ensuring efficient handling of heavy loads. Its maximum hydraulic outreach of 18 meters provides excellent flexibility, while the wide slewing angle of endless and slewing torque of 7 meters help improve maneuverability. The crane is powered by a hydraulic system with a pump capacity of 80L/min-100L/min and operates at a pressure of 35 MPa for optimal performance. Despite its powerful features, it maintains a compact and manageable weight of 7314kg. The hydraulic outriggers provide a wide span of 8600 mm, ensuring stability and safety during operation.
Stiff Boom Crane Series SPK74002F Application Areas
Construction Site: Used for lifting heavy building materials such as steel beams, concrete slabs, etc. on construction sites.
Ports and logistics: used for lifting, loading and unloading of containers.
Transportation and installation: Widely used in the transportation and installation of large mechanical equipment.
Power and Energy: Used for lifting heavy equipment in power construction projects.
Technical Specifications
| Knuckle Boom Crane Series | SPK74002F |
| Hydr. Boom Extensions | 7 |
| Lifting Moment | 70.1 mt |
| Max. Lifting Capacity | 21000 kg |
| Max. Hydraulic Outreach | 18 m |
| Slewing Angle | endless |
| Slewing Torque | 7 mt |
| Pump Capacity | 80 L/min-100 L/min |
| Standard Crane Weight | 7314 kg |
| Operating Pressure | 35 Mpa |
| Lead Time | 15-30 Working Days |
| Payment Terms | T/T ,L/C |
Truck Model | Lifting Moment | Max. Lifting Capacity | Max.Hydraulic Outreach | Operating Pressure |
| SPK74002F | 70.1 mt | 21000 kg | 18 m | 35 Mpa |
| —–END—– | ||||
| Main Parameters | ||||
| Knuckle Boom Crane Series | SPK74002F | Hydr. Boom Extensions | 7 | |
| Lifting Moment | 70.1 mt | Max. Lifting Capacity | 21000 kg | |
| Max. Hydraulic Outreach | 18 m | Slewing Angle | endless | |
| Slewing Torque | 7 mt | Pump Capacity | 80 L/min-100 L/min | |
| Operating Pressure | 35 Mpa | Standard Crane Weight | 7314 kg | |
| Outrigger span（mm） | ||||
| R3X: 8600 mm | ||||
| —–END—– | ||||
What is the price?
Our prices are determined by many factors, including model, power, product configuration, quantity, price terms (FOB, CIF, CPT, FCA, etc.), etc.
Is there a warranty and how long is it?
We can provide warranty service. The warranty period for different models is different. It depends on the specific situation and can be negotiated.
Is the Price Reasonable?
We are the original manufacturer and can give you the most suitable price. The key to dealing with Chinese suppliers is to find and choose reliable business partners who will not deceive you for short-term business, but aim to establish a long-term career and lifelong partnership. EMAC is one of the reliable partners. We will not pursue short-term high profits, but we care about our decades of good reputation. Our cooperation with all business partners is not only as suppliers and customers, but also as close friends and brothers.
How about after-sales service and maintenance?
We provide repair and maintenance services abroad. In addition, we can provide end customers with electronic versions of “Engine Operation and Maintenance Manual”, “Parts Atlas”, “Repair Manual” and other materials, covering the full range of export products, and provide reliable technical guidance for market service training.
Note: All Above Data are Just for Reference, All Data Might Change Without Notices or Updates, Please Contact Our Sales Team to Confirm All Details Via WhatsApp or Email.
